Energy consumption reducer for lighting systems

Consumption reduction up to 40% at any type of lighting system, mainly for discharge sodium vapor lamps or high pressure mercury vapor lamps. Absorbs input voltage fluctuations as for example night overvoltages, being an additional energy saving. Astronomic switch in order to control Power On-Saving-Power OFF of the equipment.

Specifications

Specifications



Potencia 5 ÷ 60 kVA
Tensión entrada
230 V             (serie RCM)
3 x 400 V + N (serie RCT)
Tensión salida 184 V (Sodio)
207 V (Mercurio)
230 V (Encendido)
Frecuencia 50/60 Hz
Temp. Ambiente 30 ºC
Índice de protección IP-23
Refrigeración Natural
Protecc. choque elec.
Clase I
Protección por fase
Magnetotérmico
Margen T. entrada
± 10% (modo ahorro)
Indicador luminoso Azul (encendido)
Verde (ahorro)
Display digital Tensión de salida
Programación Reloj astronómico
Marcado CE
Norma IEC/UNE-EN 61558-1
IEC/UNE-EN 60076-11
IEC/UNE-EN 61439-1





Downloads

Contact us for further information

Contact us for further information

Please read the Terms of Service and Privacy Policy and confirm you agree with them before sending the form.


Referencias 1 a 1 de 1
  ATNS003 ATNS005 ATNS008 ATNS010 ATNS012 ATNS016 ATNS020 ATNS025 ATNS031 ATNS040 ATNS050 ATNS063 ATNS080 ATNS100 ATNC003 ATNC005 ATNC008 ATNC010 ATNC012 ATNC016 ATNC020 ATNC025 ATNC031 ATNC040 ATNC050 ATNC063 ATNC080 ATNC100
Request offer Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request Request
Power (VA) 3000 5000 8000 10000 12000 16000 20000 25000 31500 40000 50000 63000 80000 100000 3000 5000 8000 10000 12000 16000 20000 25000 31500 40000 50000 63000 80000 100000
PRI (V) 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400
SEC (V) 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400
IP 00 00 00 00 00 00 00 00 00 00 00 00 00 00 23 23 23 23 23 23 23 23 23 23 23 23 23 23
Phases Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase Three-phase
Use Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator Neutral Generator
Frequency 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Ambient temperature 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 40ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC 30ºC
Thermic class F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC) F (155ºC)
Electric shock protection Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I Classe I
Test voltage 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV 3 kV
A 180 180 240 240 240 240 300 300 300 300 360 360 420 420 230 230 300 370 300 300 300 370 370 370 475 475 545 545
B 100 120 150 155 165 190 180 190 190 220 205 225 225 235 145 145 185 225 185 185 185 225 225 225 345 345 385 385
C 190 190 265 265 265 270 320 325 325 325 375 380 435 435 245 245 305 375 305 305 305 375 375 375 520 520 615 615
D 140 160 200 200 200 200 200 200 200 200 320 320 350 350 205 205 265 325 265 265 265 325 325 325 320 320 350 350
E 75 75 85 85 95 120 95 105 105 135 125 145 140 150 125 125 165 205 165 165 165 205 205 205 320 320 360 360
ø 7 7 7 7 7 7 11 11 11 11 11 11 11 11 7 7 7 7 7 7 7 7 7 7 10 10 10 10
Weight (Kg) 8 9 11 12 13 20 24 28 28 39 46 57 70 79 9 12 15 17 18 25 27 32 36 47 59 70 86 95
Type 1 1 1 1 1 1 1 1 1 1 1 1 1 1 XTC100E XTC100E XTC101E XTC102E XTC101E XTC101E XTC101E XTC102E XTC102E XTC102E XTC103E XTC103E XTC104E XTC104E
Group ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0 ZN0



* TORYTRANS se reserva el derecho a modificar los datos técnicos en

cualquier momento y sin previo aviso. El diseño, dimensiones y peso de

producto podrían ser distintos. *
