Series TC
Single-phase compact control transformer
Series TC
Single-phase compact control transformer
Single-phase transformer for control, safety and separation of circuits, its compact design saves space in the assembly of electrical panels. It ensures correct operation thanks to its resettable bimetallic thermal relay that protects it against overtemperatures and overloads.
Features
- Enclosure made of self-extinguishing V0 polyamide, halogen and phosphor free, prevents the user from accessing hazardous contact parts.
- Connection with screw terminal and pre-inserted pressure washer.
- Voltage indicator LED.
- Selection of secondary voltage by means of built-in jumpers.
- DIN rail fast fixing.
Specifications
| Power (VA) | 25, 40, 63 y 100 VA |
| PRI Voltage (V) | 230 - 400 V |
| SEC Voltage (V) |
12 - 24 V 115 - 230 V |
| Frequency | 50/60 Hz |
| Ambient Temperature | 40ºC |
| Thermic Class | B (130 ºC) |
| PI | IP20 |
| Electric Shock Protection | Clase II |
| Test Voltage | 4kV |
| Regulations |
IEC/UNE-EN 61558-1 IEC/UNE-EN 61558-2-2 |
| UL Regulations |
IEC/UNE-EN 61558-2-6 IEC/UNE-EN 61558-2-4 |
Quality Seals
Uses
Intended for supplying power to control, manoeuvring and signalling elements in electrical panels of machines, equipment and processes.
Applications requiring reduced or increased voltages to provide electrical isolation for security, artificial vision, lighting, audio and video systems.
Product Versions
| References | POWER (VA) | INTENSITY - PRIMARY (A) | INTENSITY - SECONDARY (A) | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Nominal | Snapshot | 230V | 400V | 12V | 24V | 115V | 230V | ||
| TC100-1 | 100 | 150 | 0.435 | 0.25 | 8.333 | 4.167 | - | - | Show details |
| TC025-3 | 25 | 45 | 0.109 | 0.062 | - | - | 0.217 | 0.109 | Show details |
| TC040-3 | 40 | 70 | 0.174 | 0.1 | - | - | 0.348 | 0.174 | Show details |
| TC063-3 | 63 | 100 | 0.274 | 0.158 | - | - | 0.548 | 0.274 | Show details |
| TC100-3 | 100 | 150 | 0.435 | 0.25 | - | - | 0.87 | 0.435 | Show details |
| TC025-1 | 25 | 45 | 0.109 | 0.062 | 2.083 | 1.042 | - | - | Show details |
| TC040-1 | 40 | 70 | 0.174 | 0.1 | 3.333 | 1.667 | - | - | Show details |
| TC063-1 | 63 | 100 | 0.274 | 0.158 | 5.25 | 2.625 | - | - | Show details |
* TORYTRANS reserves the right to modify the information in any time and
without prior notice. Design, dimensions or weight of the product could be
different.
